AF7115MZTW
Marca:
Codice del prodotto:
AF7115MZTW - Edge
Il Edge AM7115MZTW - Edge da 5 megapixel offre immagini a livello macro con capacità di zoom. Questo microscopio include un polarizzatore per ridurre i riflessi e dispone della funzione FLC per una illuminazione regolabile. Il AF7115MZTW è compatibile con il trasmettitore Wi-Fi opzionale WF-20.
Le principali caratteristiche del AM7115MZTW - Edge sono:
• Sensore da 5 megapixel
• Ottica macro zoom
• Polarizzatore regolabile
• Resistente alloggiamento in metallo
• Controllo LED flessibile (FLC)
• Alta risoluzione ottica
• Interfaccia adattabile
• E altro ancora...
| MAGNIFICATION RATE | WORKING DISTANCE* | FIELD OF VIEW(X) | FIELD OF VIEW(Y) | DEPTH OF FIELD |
|---|---|---|---|---|
| Listed values may differ slightly |
* Without front cap | Unit = mm | ||
| T Zone | ||||
| 50 | 23 | 8 | 6 | 4 |
| 40 | 43 | 10 | 7 | 6 |
| 30 | 43 | 13 | 10 | 11 |
| 20 | 128 | 20 | 15 | 27 |
| 15 | 183 | 26 | 20 | 48 |
| MAGNIFICATION RATE | WORKING DISTANCE* | FIELD OF VIEW(X) | FIELD OF VIEW(Y) | DEPTH OF FIELD |
|---|---|---|---|---|
| Listed values may differ slightly |
* Without front cap | Unit = mm | ||
| W Zone | ||||
| 30 | 19 | 13 | 10 | 7 |
| 20 | 33 | 20 | 15 | 7 |
| 15 | 47 | 26 | 20 | 25 |
| 10 | 76 | 40 | 30 | 57 |
| 5 | 163 | 79 | 59 | 297 |
| Lighting | |
|---|---|
| Light/ LED type | White |
| Number of LEDs | 8 |
| LED on/off switchable: | Yes |
| Diffuser available | Yes (N3C-D included) |
| Emission filter | No |
| Polarizer | Yes, linear |
| Optics | |
| Magnification | 10x ~ 50x |
| Macro zoom | No |
| Working distance | Standard |
| Lens type | Glass with anti-reflection coating |
| Sensor | |
| Sensor type | CMOS |
| Resolution | 5 Megapixel (2592x1944) |
| Maximum frame rate | 30 fps |
| Compatibility | |
| Interface | USB 2.0 |
| Operating system | Windows 7, 8, 10 & 11, MacOS 10.14 and up |
| Software | DinoCapture 2.0 (Windows), DinoXcope (Mac OS) |
| Supported image formats (Windows) | BMP, GIF, PNG, MNG, TIF, TGA, PCX, WBMP, JP2, JPC, JPG, PGX, RAS, PNM |
| Supported video formats (Windows) | WMV, FLV, SWF |
| Supported image formats (MacOS) | JPEG, PNG |
| Supported video formats (MacOS) | MOV (max 1.3MP) |
| Imaging standards | DirectShow, UVC |
| Wifi | Wireless-ready, requires the WF-20 adapter (optional) |
| Housing | |
| Housing material | Metal housing |
| Magnification lock | Yes |
| Dimensions | 15 mm (H) x 34 mm (D) |
| Weight | 97g |
| Cable length | 1.8m |
| Features | |
| Special feature | Flexible LED Control (FLC) |
| Measurement | Yes |
| Calibration | Yes |
| Microtouch sensor | Yes |
| ESD safe | Yes |
| Information | |
| Package contents | Microscope, carry pouch, software CD, calibration target, user manual, N3C-O- Open cap, N3C-C- Closed cap, N3C-D- diffuser cap, N3C-E- extension cap, N3C-L- Long cap, N3C-S- Side light cap |
| Warranty information | 2 years European warranty |
| Regulatory approval | CE, FCC, ROHS |
| Price range | €900,00 - €1100,00 |
