IriScope (MEDL4R)
Marca:
Dino-Lite Medical
Codice del prodotto:
MEDL4R
Iriscope (MEDL4R) offre un modo nuovo, semplice e veloce per scattare fotografie degli occhi. Iriscope ha LED 2x2 (bianco/giallo) che illuminano il lato dell'occhio riducendo i riflessi nell'immagine, nonché il disagio di una luce brillante. I LED gialli forniscono immagini migliori delle iridi scure. Le immagini hanno una risoluzione massima di 1,3 Megapixel.
| Lighting | |
|---|---|
| Light/ LED type | White/ Yellow |
| Number of LEDs | 2+2 |
| LED on/off switchable: | Yes |
| Infrared filter | IR cut-filter >650 nm |
| Diffuser available | No |
| Polarizer | No |
| Optics | |
| Magnification | 10-20x |
| Lens type | Glass with anti-reflection coating |
| Sensor | |
| Sensor type | CMOS |
| Resolution | 1.3 Megapixel (1280x1024) |
| Maximum frame rate | 30 fps |
| Compatibility | |
| Interface | USB 2.0 |
| Operating system | Windows 7, 8, 10 & 11, MacOS 10.9 and up |
| Software | DinoCapture 2.0 (Windows), DinoXcope (Mac OS) |
| Supported image formats (Windows) | BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX |
| Supported video formats (Windows) | WMV, FLV, SWF |
| Supported image formats (MacOS) | JPEG, PNG |
| Supported video formats (MacOS) | MOV |
| Imaging standards | DirectShow, UVC |
| Housing | |
| Housing material | Composite/plastic housing |
| Magnification lock | Yes |
| Dimensions | 10.5cm (L) x 3.2cm (D) |
| Weight | 95 g |
| Cable length | 1.8m |
| Features | |
| Special feature | No |
| Measurement | No |
| Calibration | No |
| Microtouch sensor | Yes |
| Information | |
| Package contents | Microscope, carry pouch, software CD, user manual |
| Warranty information | 2 years European warranty |
| Regulatory approval | Medical Device Class 1 – Medical Devices Regulation (EU) 2017/745 |
| Price range | €500,00 - €700,00 |
