AM8517MT-FUW
Marca:
Codice del prodotto:
AM8517MT-FUW
Dotato di illuminazione duale, il microscopio AM8517MT-FUW da 8 megapixel presenta LED da 375 nm per applicazioni UV e LED bianchi per un'imaging ad alta fedeltà cromatica. Questo microscopio è adatto per ispezioni industriali, analisi forensi, rilevamento di contraffazioni e altre applicazioni in cui sono richieste immagini di alta qualità e illuminazione UV.
| M | WD | FOV (x) | FOV (y) | DOF |
|---|---|---|---|---|
| 20 | 57.5 | 30.35 | 17.07 | 5.94 |
| 30 | 31.8 | 20.23 | 11.38 | 2.84 |
| 40 | 19.7 | 15.17 | 8.53 | 1.71 |
| 50 | 13.0 | 12.14 | 6.83 | 1.17 |
| 60 | 9.0 | 10.11 | 5.69 | 0.86 |
| 70 | 6.6 | 8.67 | 4.88 | 0.67 |
| 80 | 5.2 | 7.59 | 4.27 | 0.54 |
| 90 | 4.4 | 6.74 | 3.79 | 0.45 |
| 100 | 4.0 | 6.07 | 3.41 | 0.38 |
| 110 | 4.0 | 5.52 | 3.10 | 0.33 |
| 120 | 4.3 | 5.06 | 2.85 | 0.29 |
| 130 | 4.7 | 4.67 | 2.63 | 0.26 |
| 140 | 5.3 | 4.34 | 2.44 | 0.23 |
| 150 | 6.0 | 4.05 | 2.28 | 0.21 |
| 160 | 6.8 | 3.79 | 2.13 | 0.19 |
| 170 | 7.6 | 3.57 | 2.01 | 0.18 |
| 180 | 8.6 | 3.37 | 1.90 | 0.16 |
| 190 | 9.6 | 3.20 | 1.80 | 0.15 |
| 200 | 10.6 | 3.03 | 1.71 | 0.14 |
| 210 | 11.7 | 2.89 | 1.63 | 0.13 |
| 220 | 12.8 | 2.76 | 1.55 | 0.12 |
| Lighting | |
|---|---|
| Light/ LED type | White LED | 375 nm LED |
| Optics | |
| Magnification | 20x ~ 220x |
| Sensor | |
| Resolution | 8.0 Megapixel (3840 x 2160) |
| Maximum frame rate | 10 fps at 8.0 MP, MJPEG 25 fps at 2.0 MP, MJPEG |
| Compatibility | |
| Interface | USB 2.0 |
| Operating system | Windows 10/11 macOS 10.14 or later |
| Supported image formats (Windows) | DinoCapture 2.0: BMP, GIF, PNG, MNG, TIF, TGA, PCX, WBMP, JP2, JPC, JPG, PGX, RAS, PNM |
| Supported video formats (Windows) | DinoCapture 2.0: WMV, FLV, SWF |
| Supported image formats (MacOS) | DinoXcope: PNG, JPEG |
| Supported video formats (MacOS) | DinoXcope: MOV |
| Housing | |
| Magnification lock | Yes |
| Dimensions | 130 mm (H) x 32 mm (D) |
| Weight | Approx. 118 g |
| Cable length | Approx. 1.8 m |
| Features | |
| Measurement | Yes |
| Calibration | Yes |
| Microtouch sensor | Yes |
| Information | |
| Package contents | Microscope, carry pouch, calibration target, user manual, N3C-O- Open cap, N3C-C- Closed cap, N3C-D- Diffuser cap, N3C-E- Extension cap, N3C-L- Long cap, N3C-S- Side light cap |
| Warranty information | 2 years European warranty |
| Regulatory approval | CE, FCC, ROHS |
| Price range | €1250,00 - €1400,00 |
