AM8917MZTL
Marca:
Dino-Lite
Código del producto:
AM8917MZTL Edge Plus
Captura imágenes impresionantes con el microscopio digital de distancia de trabajo larga AM8917MZTL de 8 megapíxeles. Diseñado con un conjunto completo de funciones, incluido AMR, este modelo está diseñado para destacar tanto en tareas de imagen como en tareas orientadas a la medición.
Las principales características del AM8917MZTL son:
• 8 megapíxeles
• Alta resolución óptica
• Lectura automática de magnificación (AMR)
• Profundidad de campo extendida (EDOF)
• Rango dinámico extendido (EDR)
• Adquisición de profundidad (DPQ)
• Control mejorado de LED flexibles (eFLC)
• Óptica de distancia de trabajo larga (LWD)
• Polarizador ajustable
• Carcasa metálica resistente
• Aumento de 10x a 140x (La sombra en los bordes ocurre por debajo de 25x al previsualizar en ventanas 16:9.)
• Y mucho más...
| MAGNIFICATION RATE | WORKING DISTANCE * | FIELD OF VIEW(X) | FIELD OF VIEW(Y) | DEPTH OF FIELD |
|
10 |
237.5 |
60.69 |
34.14 |
25.82 |
|
20 |
115.3 |
30.35 |
17.07 |
6.89 |
|
30 |
75.9 |
20.23 |
11.38 |
3.50 |
|
40 |
57.3 |
15.17 |
8.53 |
2.23 |
|
50 |
47.0 |
12.14 |
6.83 |
1.59 |
|
60 |
40.8 |
10.11 |
5.69 |
1.22 |
|
70 |
36.9 |
8.67 |
4.88 |
0.98 |
|
80 |
34.6 |
7.59 |
4.27 |
0.82 |
|
90 |
33.2 |
6.74 |
3.79 |
0.70 |
|
100 |
32.6 |
6.07 |
3.41 |
0.61 |
|
110 |
32.4 |
5.52 |
3.10 |
0.53 |
|
120 |
32.7 |
5.06 |
2.85 |
0.48 |
|
130 |
33.2 |
4.67 |
2.63 |
0.43 |
|
140 |
33.9 |
4.34 |
2.44 |
0.39 |
| Listed values may differ slightly | * Without front cap | Unit = mm | ||
| Lighting | |
|---|---|
| Light/ LED type | White |
| Number of LEDs | 8 |
| Optics | |
| Magnification | 10x ~ 140x |
| Working distance | 237.5 ~ 33.9 mm |
| Sensor | |
| Sensor type | CMOS |
| Resolution | 8 Megapixel (3840 x 2160) |
| Maximum frame rate | 10 fps at 8.0 MP, MJPEG 25 fps at 2.0 MP, MJPEG |
| Compatibility | |
| Interface | USB 2.0 |
| Operating system | Windows 10/11 |
| Supported image formats (Windows) | BMP, GIF, PNG, MNG, TIF, TGA, PCX, WBMP, JP2, JPC, JPG, PGX, RAS, PNM |
| Supported video formats (Windows) | WMV, FLV, SWF |
| Housing | |
| Housing material | Metal housing |
| Dimensions | 130 mm (H) x 33 mm (D) |
| Weight | 120 g |
| Features | |
| Measurement | Yes |
| Calibration | Yes |
| Microtouch sensor | Yes |
| Information | |
| Package contents | N3C-C (Close Cap) N3C-D (Diffuser Cap) N3C-D2 (Opal Diffuser Cap) N3C-E (Extended Open Cap) N3C-L (Long Cap) N3C-O (Open Cap) N3C-S (Sidelight Cap) |
| Warranty information | 2 years European warranty |
| Regulatory approval: | CE, FCC, ROHS |
| Price range | €1500,00 - €1700,00 |
