AM4517MT-DFRW
Merk:
Productcode:
AM4517MT-DFRW
Detecteer diep-rood of nabij-infrarood (NIR) fluorescentie-uitstralingen met de AM4517MT-DFRW digitale microscoop met hoge gevoeligheid, van 20x tot 220x vergroting. Uitgerust met 620 nm excitatielichten en een 655 nm ~ 950 nm emissiefilter, legt dit model emissies vast van fluorescerende sondes zoals CY5, Alexa Fluor 647 en Qdot 655. Dit model beschikt over AMR (Automatische Vergrotingsweergave) om metingen te vergemakkelijken.
The main features of the AM4517MT-DFRW are:
- 1.3 Megapixel
- High Sensitivity Sensor
- Wide-Ranging Fluorescence Detection
- Switchable White Light
- Automatic Magnification Readout (AMR)
- Robust Metal Housing
| Magnification | Working Distance * | Field of View(x) | Field of View(y) | Depth of Field |
|---|---|---|---|---|
| Listed values may differ slightly |
* Without front cap | Unit = mm | ||
| 20x | 60.4 | 19.53 | 14.65 | 6.34 |
| 30x | 33.7 | 13.02 | 9.77 | 3.03 |
| 40x | 21.1 | 9.77 | 7.33 | 1.82 |
| 50x | 14.1 | 7.81 | 5.86 | 1.24 |
| 60x | 9.9 | 6.51 | 4.88 | 0.91 |
| 70x | 7.3 | 5.58 | 4.19 | 0.71 |
| 80x | 5.7 | 4.88 | 3.66 | 0.57 |
| 90x | 4.8 | 4.34 | 3.26 | 0.47 |
| 100x | 4.3 | 3.91 | 2.93 | 0.40 |
| 110x | 4.2 | 3.55 | 2.66 | 0.35 |
| 120x | 4.3 | 3.26 | 2.44 | 0.31 |
| 130x | 4.7 | 3.01 | 2.25 | 0.27 |
| 140x | 5.2 | 2.79 | 2.09 | 0.24 |
| 150x | 5.8 | 2.60 | 1.95 | 0.22 |
| 160x | 6.5 | 2.44 | 1.83 | 0.20 |
| 170x | 7.3 | 2.30 | 1.72 | 0.18 |
| 180x | 8.2 | 2.17 | 1.63 | 0.17 |
| 190x | 9.1 | 2.06 | 1.54 | 0.16 |
| 200x | 10.1 | 1.95 | 1.47 | 0.15 |
| 210x | 11.1 | 1.86 | 1.40 | 0.14 |
| 220x | 12.1 | 1.78 | 1.33 | 0.13 |
| Verlichting | |
|---|---|
| Licht / LED-type | 620 nm excitation + white |
| Aantal leds | 7 FL + 1 White |
| LED aan / uit schakelbaar: | Yes |
| Infrarood filter | No |
| Diffusor beschikbaar | No |
| Emissiefilter | 655 nm ~ 950 nm |
| Polarisator | No |
| Fluorophores | Y5, Alexa Fluor 647, and Qdot 655 |
| Optiek | |
| Magnification | 20x ~ 220x |
| Macro zoom | No |
| Werkafstand | Standard |
| Type lens | Glass with anti-reflection coating |
| Sensor | |
| Sensortype | CMOS |
| Resolutie | 1.3 Megapixel (1280 x 960) |
| Maximale framesnelheid | 30 fps |
| Compatibiliteit | |
| Interface | USB 2.0 |
| Besturingssysteem | Windows 7, 8, 10 & 11, MacOS 10.9 and up |
| Software | DinoCapture 2.0 (Windows), DinoXcope (Mac OS) |
| Ondersteunde beeldformaten (Windows) | BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX |
| Ondersteunde videoformaten (Windows) | WMV, FLV, SWF |
| Ondersteunde beeldformaten (MacOS) | JPEG, PNG |
| Ondersteunde videoformaten (MacOS) | MOV |
| Behuizing | |
| Materiaal van de behuizing | Metal housing |
| Vergrotingsslot | Yes |
| Afmetingen | 104 mm (H) x 32 mm (D) |
| Gewicht | 90g |
| Kabellengte | 1.8m |
| Kenmerken | |
| Bijzonderheid | Automatic Magnification Readout (AMR) |
| Meting | Yes |
| Kalibratie | Yes |
| Microtouch-sensor | Yes |
| Informatie | |
| Inhoud van de verpakking | Microscope, carry pouch, calibration target, user manual, N3C-C (Close Cap) N3C-EB (Extended Open Black Cap) N3C-LB (Black Long Cap) N3C-OB (Black Open Cap) |
| Garantie-informatie | 2 years European warranty |
| Regulatory approval: | CE, FCC, ROHS |
| Prijsklasse | €1100,00 - €1300,00 |
